Price: £TBC
Availability: Under Development
Montec Vibration Monitor overview
The battery-powered Montec Vibration Monitor (MVM) is sensitive 3 axis vibration or shock sensor that constantly ‘listens’ for events. When a vibration event happens it is captured and analysed for certain characteristics such as maximum acceleration, frequency and duration. Only these key parameters are transmitted, however the entire event data is recorded on an SD card in case the high resolution data is required. Each MVM takes a measurement every 20 minutes which it stores in its memory. Every three hours each MVM wirelessly transmits its recordings to the Montec Base Station. Levels of all recorded parameters can be pre-set, triggering an email alert if they are exceeded. MVMs are fixed with adhesive – no need to drill holes. The MVM is designed to be easy to configure and install by a non-technical person in under an hour. Up to 8 Montec Monitors of any type can be linked to one Base Station.
Montec Vibration Monitor features
- Dimensions: 110 x 85 x 37mm
- Weight: 168g
- Adaptive wireless power (only transmits with power necessary)
- Long-lasting self-contained battery (approx. 3 years)
- Long-range: up to 1100 metres between MBS and Montec Monitors (line of sight)
- Can be used indoors and outdoors
- Weather proof
Tell us your thoughts
We would love to find out if this product interests you, of if any other sensor does. We would also like to know if any other sensor would be of interest. All information is strictly confidential.
